Instrumentation for measuring pressure

Series 8000 is mechanical pressure switches in diaphragm or piston design. The successors of the product lines XTM, XTK, X1T and 96200 have the additional advantage.6 pressure ranges allow precise setting between 0,4 to 6 bar and from 80 to 600 bar. The housing is made of aluminium diecast 230 with a protection class IP¨65. The 8000-series are ideal for OEM, mobile- and industrial-hydraulics an...

The series 9000 switches with a piston-type spring-loaded pressure element and snap-acting microswitch are characterized by their compact design. The housing is made of aluminium and has a protection class IP65. 3 pressure ranges allow precise setting between 6 and 400 bar. The switch is ideal for OEM applications, hydraulic and pneumatic systems.

Piston pressure switch with explosion proof housing, for hazardous areas. Safe to adjust during operation. Measuring ranges available from 0,1 to 1 bar and from 3,4 to 34,5 bar. This switch is ideal for process Industry, petrochemical plants, machine tool industry, compressors.

Piston pressure switch with explosion proof housing, for hazardous areas. Safe to adjust during operation. Measuring ranges available from 17,2 to 571 bar. This switch is ideal for process Industry, petrochemical plants, machine tool industry, compressors.

Bourdon tube pressure switches with direct-acting pressure sensor and the snap-acting micro switch provide very high accuracy and long life span. Main features are that the wetted parts are welded, direct acting, no friction and high accuracy Available with 1 (B1T) or 2 (B2T)setpoints. Measuring ranges from 5,3 to 496 bar. Main Applications : pump control, die-casting machines, press control,...

Metal diaphragm pressure switches with direct-acting pressure sensor and the snap-acting micro switch provide very high accuracy and long life span. Main features are that the wetted parts are welded, direct acting, no friction and high accuracy. Available with 1 (D1T) or 2 (D2T)setpoints. Measuring ranges from -0.006 ... -1 bar up to 0.005 ... 10.3 bar. Main applications are petrochemicals i...

Mechanical pressure switch with stainless steel diaphragm for pressure control in explosion-proof areas. Adjustment ranges from 1 mbar up to 10 bar. Available with 1 contact (D1X) or 2 contacts (D2X).

Pressure switch E1H provide high accuracy, long life span and high proof pressure due to their design diaphragm seal piston. It can be equipped with manual reset for alarm functions.

Electronic pressure switch for pressure control with internal stainless steel diaphragm, with 2 solid state outputs or 1 solid state output with adjustable hysteresis. Measuring ranges available from 0 ...10 bar to 0...600 bar. The UDS1V2 is ideal for OEM applications in hydraulic and pneumatic systems

Electronic pressure switch for pressure control with internal stainless steel diaphragm, digital display, 4 switching outputs and 1 analog output. OEM applications, hydraulic and pneumatic systems, heavy industry and plant engineering, automobile industry

The Barksdale BPS3000 series is an electronic pressure switch with optional transmitter output. The pressure switch is equipped with a LED display and is fully rotatable in the ideal position. The display and electrical connection can be rotated separately. In addition to the standard models the BPS300 can also be equipped out with other process connections, analog output or EPDM gaskets.

The FineTek SQ series pressure switch is ideal for building in industrial machines and hydraulic power packs due to its compact size. There are standard versions of 10 to 300 bar with an adjustable switching point and a DIN43650 form A connector for the electrical connection. Optionally there are also custom models with an NPT process connection, a fixed switching point and choice of other mate...

The 425X series from Barksdale is a compact explosion-proof pressure transmitter. The compact size makes the 425X suitable as an OEM transmitter for machines and hydraulic powerpacks that are used in an ATEX zone. There are a large number of measuring ranges up to 689 bar relative pressure and optionally also absolute pressure.

The Barksdale UPA2 series consists of very robust pressure transmitters with high accuracy. The UPA2 series is available in a pressure range of 1 bar up to 800 bar. These industrial pressure transmitters can also be used in shipping by the GL ship's approval.

The Barksdale 450 series is a compact and intelligent pressure transmitter with Hart communication. The compact shape makes the pressure sensor easy to build into a machine without taking up too much space. The 450 series is suitable for various applications including; hydraulics (power packs), water treatment and various other industrial processes. The 450 series pressure transmitter communica...

The Barksdale 450X series is an explosion-proof, compact and intelligent pressure transmitter with Hart communication. The compact shape makes the pressure sensor easy to build in a machine without taking up too much space. The 450X series is suitable for various applications including; hydraulics (power packs), water treatment and various other industrial processes. The 450X series pressure tr...

The BoT series digital pressure transducers are designed to monitor and control pressure in gas installations, mobile hydraulic equipment and vehicles, among others, exactly when you need it. Barksdale's BoT series pressure transmitters are configurable from 55 available standard options, but can also be completely customised.

Klay-Instruments' series 8000 is a complete line of pressure transmitters that can also be used for level measurement. The transmitters are made entirely of stainless steel and have a very strong front membrane. These diaphragms offer high protection against overpressure and prevent coagulation and accumulation of the medium in the pressure transmitter. The transmitters are ideally suited for i...

De serie 2000 van Klay-Instruments is een complete lijn ‘intelligente’ druktransmitters die ook als niveautransmitter kan worden gebruikt. De transmitters zijn microprocessor gestuurd en eenvoudig instelbaar d.m.v. drie druktoetsen in een geheel RVS behuizing. Het display en de druktoetsen maken de transmitter gemakkelijk in te stellen. De drukzenders zijn voorzien van een voorliggend membraan...

De serie 4000 van Klay-Instruments is een complete lijn intelligente druktransmitters die ook als niveautransmitter kan worden gebruikt en zijn microprocessor gestuurd. De transmitters zijn eenvoudig instelbaar met slechts één programmeerknop en hebben een RVS behuizing. Door de unieke ‘One Touch Programming Button’ zijn zero en span zonder testdruk instelbaar, en afleesbaar op het standaard ge...

Bourdon tube explosion proof pressure switches with direct-acting pressure sensor and the snap-acting microswitch provide very high accuracy and long life span. Ranges available from 5 to 950 bar, with 1 (B1X) or 2 (B2X) separate setpoints.

The Foxboro IAP10 series is a compact and robust absolute pressure transmitter for direct process mounting. The IAP10 series is available in different measuring ranges of 2.1 bar, 21 bar and 210 bar absolute pressure. As signal output you can choose 1-5V, 4-20 mA, Hart, Foudation Fielbus and FoxCom. The IAP10 series is available in a safe area version or explosion-proof version according to ATE...

The Foxboro IGP10 series is a compact and robust gauge pressure transmitter for direct process mounting. The IGP10 series is available in different measuring ranges of 500 mbar, 2.1 bar, 21 bar and 210 bar relative pressure. As signal output you can choose 1-5V, 4-20 mA, Hart, Foudation Fielbus and FoxCom. The IGP10 series is available as a safe area version, but also as an explosion-proof vers...

The Foboro Accutech series consists of these pressure transmitters. The GP10 is a wireless relative (guage) pressure transmitter for static pressure measurement with a range of 250 to 10,000 psig (17 - 690 Barg). The AP10 series is a wireless absolute pressure transmitter with a range of 30 to 250 psig (2 - 17 BarA). The Accutech transmitters communicate with the Accutech base station over dist...
