Pressure transmitters and pressure switches for the chemical and process industry

Model 1950 explosion proof pressure pressure switch combines the best features of the popular1900 series with an integral explosion-proof and weatherproof housing, making it an exceptional value for either application. It is CE, UL and CSA listed, FM approved for use in Class I, Div 1, Groups C and D, Class II Groups E, F, and G and Class III hazardous atmospheres (NEMA 7 & 9), Raintight NEMA 3...

The Model 1950G Explosion-Proof Switch combines the best features of the popular Dwyer® Series 1950 Pressure Switch with the benefit of natural gas compatibility. Units are rain-tight for outdoor installations, And are ATEX approved CE ATEX II 2G Exd IIB+H2 T6. Adjustment to the set point of the switch can be made without disassembly of the housing.

Bourdon tube pressure switches with direct-acting pressure sensor and the snap-acting micro switch provide very high accuracy and long life span. Main features are that the wetted parts are welded, direct acting, no friction and high accuracy Available with 1 (B1T) or 2 (B2T)setpoints. Measuring ranges from 5,3 to 496 bar. Main Applications : pump control, die-casting machines, press control,...

Bourdon tube explosion proof pressure switches with direct-acting pressure sensor and the snap-acting microswitch provide very high accuracy and long life span. Ranges available from 5 to 950 bar, with 1 (B1X) or 2 (B2X) separate setpoints.

Metal diaphragm pressure switches with direct-acting pressure sensor and the snap-acting micro switch provide very high accuracy and long life span. Main features are that the wetted parts are welded, direct acting, no friction and high accuracy. Available with 1 (D1T) or 2 (D2T)setpoints. Measuring ranges from -0.006 ... -1 bar up to 0.005 ... 10.3 bar. Main applications are petrochemicals i...

Mechanical pressure switch with stainless steel diaphragm for pressure control in explosion-proof areas. Adjustment ranges from 1 mbar up to 10 bar. Available with 1 contact (D1X) or 2 contacts (D2X).

Pressure switch E1H provide high accuracy, long life span and high proof pressure due to their design diaphragm seal piston. It can be equipped with manual reset for alarm functions.

Explosion-proof, heavy duty, industrial pressure switch which provides sensitivity to differential pressure as low as 25 mbar up to 14 bar with a max. static pressure of 100 bar. This unit has a standard aluminium pressure chamber but is also available in 316 stainless steel. Approvals : UL, CSA, CE and ATEX.

Dwyer SA 1100 is an extremely rugged pressure switch that assures excellent reliability. The pressure switch has a visual setpoint and an adjustable deadband, up to 5% of measuring range. Wetted parts are available in aluminium and stainless steel.

The ATEX-certified AT2MS series Magnesense® differential pressure transmitter is an extremely versatile transmitter for monitoring pressure and air velocity in potentially hazardous areas. The AT2MS transmitter can be set up in English or metric ranges and can be extended with an LCD screen. A square root output can be set for use with pitot tubes and similar flow sensors. The flameproof ATEX h...

The Foxboro IAP10 series is a compact and robust absolute pressure transmitter for direct process mounting. The IAP10 series is available in different measuring ranges of 2.1 bar, 21 bar and 210 bar absolute pressure. As signal output you can choose 1-5V, 4-20 mA, Hart, Foudation Fielbus and FoxCom. The IAP10 series is available in a safe area version or explosion-proof version according to ATE...

The Foxboro IGP10 series is a compact and robust gauge pressure transmitter for direct process mounting. The IGP10 series is available in different measuring ranges of 500 mbar, 2.1 bar, 21 bar and 210 bar relative pressure. As signal output you can choose 1-5V, 4-20 mA, Hart, Foudation Fielbus and FoxCom. The IGP10 series is available as a safe area version, but also as an explosion-proof vers...

The Foxboro IDP10 series is a compact and robust differential pressure transmitter for direct process mounting. The IDP10 series is available in different measuring ranges of 75 mbar, 500 mbar, 2.1 bar, 21 bar and 210 bar differential pressure. As signal output you can choose 1-5V, 4-20 mA, Hart, Foudation Fielbus and FoxCom. The IDP10 series can be designed as a differential pressure transmitt...

The Foboro Accutech series consists of these pressure transmitters. The GP10 is a wireless relative (guage) pressure transmitter for static pressure measurement with a range of 250 to 10,000 psig (17 - 690 Barg). The AP10 series is a wireless absolute pressure transmitter with a range of 30 to 250 psig (2 - 17 BarA). The Accutech transmitters communicate with the Accutech base station over dist...

The Foxboro Accutech series includes these wireless differential pressure transmitters. The DP20 is a wireless differential pressure transmitter with ranges up to +/- 300in H20 (+/- 762mm H2O). The Accutech transmitters communicate with the Accutech base station over distances up to 48 km.

The IAP05S series is a budget-friendly pressure transmitter within the Schneider Electric range and is standard SIL2 certified. The IAP05S measures an absolute pressure with an accuracy of 0.075% of the chosen measuring range, varying from 50 kPa to 345 bar. This makes the IAP05S pressure transmitter somewhat less accurate than its bigger brothers, but also a lot cheaper. For less demanding app...

The IGP05S series is a budget-friendly pressure transmitter within the Schneider Electric range and is standard SIL2 certified. The IGP05S measures a relative pressure with an accuracy of 0.075% of the selected measuring range, ranging from 50 kPa to 345 bar. This makes the IGP05S pressure transmitter less accurate than its bigger brothers, but also a lot cheaper. For less demanding application...

The IDP05S series is a budget-friendly differential pressure transmitter within the Schneider Electric range with standard SIL2 certification. The IDP05S measures a pressure difference with an accuracy of 0.075% of the chosen measuring range, ranging from 50 kPa to 207 bar. This makes the IDP05S differential pressure transmitter less accurate than its bigger brothers, but also a lot cheaper. Fo...

The IAP10S series is a very robust and advanced pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IAP10S measures an absolute pressure with an accuracy of 0.05% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the same model of pressure trans...

The IGP10S series is a very robust and advanced pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IGP10S measures a relative pressure with an accuracy of 0.05% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the same model of pressure transm...

The IDP10S series is a very robust and advanced differential pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IDP10S measures a pressure difference with an accuracy of 0.05% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the same model of...

The IAP50S series is a very robust and extremely accurate pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IAP50S measures an absolute pressure with an accuracy of 0.025% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the same model IAP50S...

The IGP50S series is a very robust and extremely accurate gauge pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IGP50S measures a relative pressure with an accuracy of 0.025% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the same model...

The IDP50S series is a very robust and extremely accurate differential pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IDP50S measures a pressure difference with an accuracy of 0.025% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the sam...
