Differential pressure gauges

These inexpensive manometers measure positive, negative and differential pressures. Dwyer Flex-Tube U-Tube Manometers combine the inherent accuracy of the simple "U" Tube with the durability of tough, long-lasting plastic construction. Series 1221 Manometer, the simplest, lowest cost basic U-gage. Series 1222 Manometer, alll the features of the 1221 plus magnetic clips. Series 1223 Manometer, t...

Dwyer Magnehelic gage for high accuracy, guaranteed within 2% of full scale and for the wide choice of 81 models available to suit your needs precisely. Using Dwyer's simple, frictionless Magnehelic gage movement, it quickly indicates low air or noncorrosive gas pressures, either positive, negative (vacuum) or differential. The design resists shock, vibration and over-pressures. No manometer fl...

The Minihelic is a small differential pressure manometer, suitable for many of the same applications as the Magnehelic gage where the greater accuracy, sensitivity, and higher and lower differential pressure ranges of the Magnehelic gage are not required. It can safely operate at total pressures up to 200 kPa. With the housing molded from mineral and glass filled nylon and the lens molded from...

The series 3000MR Photohelic switch/gages combine the functions of a precise, highly repeatable differential pressure switch with a large easy-to-read analog pressure gage employing the durable, time-proven Magnehelic gage design. The Photohelic has 2 switch functions. Switch setting is easy to adjust with large external knobs on the gage face. Gage reading is unaffected by switch operation — w...

The Capsuhelic gage is designed to give fast, accurate indication of differential pressures. The gage may be used as a readout device when measuring flowing fluids, pressure drop across filters, liquid levels in storage tanks and many other applications involving pressure, vacuum or differential pressure.

The Series 605 Magnehelic Indicating Transmitter provides for both visual monitoring and electronic control of very low differential pressure. The Series 605 is ideal for control applications in building HVAC systems The easily read dial gage is complimented by the two-wire, 4-20 mA control signal utilizing the timeproven Dwyer® Magnehelic® gage mechanical design and Series 600 transmitter tech...

The Dwyer series DM-2000 differential pressure transmitter senses the pressure of air and compatible gases and sends a standard 4-20 mA output signal. The DM-2000 housing is specifically designed to mount in the same diameter cutout as a standard Magnehelic gage. A wide range of models are available factory calibrated to specific ranges. Pressure connections are inherent to the glass filled pla...

The HP range of inclined liquid column manometers, measure slight variations in pressure, depression or differential pressure of air or gas. The are particulary recommended for measuring overpressure in clean rooms, laboratories, aseptic rooms and laminar flows.

Dwyer Mark II series molded manometers are of the inclined and inclined-vertical types. The curved inclined-vertical tube of the Mark II manometers can be mounted on any vertical surface with the two mounting screws provided. Ranges available from 0-80 mmH2O and from -10 to + 700 Pa.

The MP Mini-Photohelic differential pressure switch/gage combines the time proven Minihelic II differential pressure gage with two SPDT switching setpoints. The Mini-Photohelic gage is designed to measure and control positive, negative, or differential pressures consisting of non-combustible and non-corrosive gases. Gage reading is independent of switch operation. This extremely compact switch...

The 2000-HA Series High Accuracy Magnehelic® pressure differential manometer is twice as accurate as the standard Magnehelic® manometer. The High Accuracy Magnehelic® pressure differential manometer provides a mirrored overlay to eliminate any parallax errors when measuring. A six-point calibration certificate is included with any high-precision model. The robust IP67 housing (front) helps to c...

The 1201 series pressure gauges are available with housings of aluminum, stainless steel or brass. Optionally there is also a waterproof housing or explosion proof version available. The maximum static pressure is 350 bar. The measuring element is a piston-type. The Orange Research instruments are ideal for monitoring filters for gas and liquid.

With the explosion-proof AT22000 series, the popular Magnehelic® differential pressure manometer is now also available in a flame proof ATEX housing. This manometer measures underpressure, overpressure, or pressure difference. Popular applications are filter monitoring, room pressure monitoring and flow monitoring of a fan.
